Air King’s industrial grade floor fans provide powerful air movement to industrial and commercial spaces such as plants, gyms, garages, music studios, and restaurants. The industrial grade floor fans from Air King are available in multiple size to fit your air movement needs.
Motor:
9230, 9224: 3-speed, 1/4 HP, 120V, 1 phase, totally enclosed, ball bearing, permanently lubricated, permanent split capacitor.
9220, 9219, 9218: 3-speed, 1/6 HP, 120V, 1 phase, totally enclosed, ball bearing, permanently lubricated, permanent split capacitor.
9214: 3-speed, 1/20 HP, 120V, 1 phase, totally enclosed, ball bearing, permanently lubricated, permanent split capacitor.
9212: 3-speed, 1/25 HP, 120V, 1 phase, totally enclosed, ball bearing, permanently lubricated, permanent split capacitor.
Controls: Rear mounted rotary switch.
Power Cord: Black, 10’, 3-conductor, SJT type.
Coating: Blade, Guard, and Mounts are Powder coated steel.
Compliance: ETL, OSHA.
This product meets the Made in America requirements of the American Recovery and Reinvestment Act as a manufactured Good. To download the Guidance PDF click here.
All fans are tested in accordance with AMCA standard 230-99.
| Floor Fans | |||
| Models | 9230 | 9224 | 9220 |
|---|---|---|---|
| Blade Size | 30″ | 24″ | 20″ |
| CFM (High/Med/Low) | 7400 / 6360 / 4980 | 5130 / 4490 / 3670 | 3670 / 3330 / 2940 |
| RPM (High/Med/Low) | 1040 / 902 / 860 | 1060 / 925 / 745 | 1500 / 1310 / 1050 |
| AMPS (High/Med/Low) | 2.4 / 1.9 / 1.5 | 2.4 / 1.9 / 1.5 | 1.6 / 1.3 / 1.1 |
| Watts (High/Med/Low) | 255 / 200 / 154 | 252 / 199 / 157 | 184 / 155 / 130 |
| dB (High/Med/Low) | 75 / 71 / 67 | 72 / 69 / 64 | 62 / 55 / 48 |
| Adjustable Height | N/A | N/A | N/A |
| Pivoting Head | Yes | Yes | Yes |
| Weight (lbs.) | 48.3 | 41.8 | 24.0 |
| Cube (feet) | 8.63 | 5.69 | 4.46 |
| Dimensions (Length/Width/Height) | 33.75″ x 12.25″ x 35.5″ | 27″ x 12″ x 28.75″ | 25.75″ x 12.5″ x 25″ |
| Specification Sheet | 9230 | 9224 | 9220 |
| Floor Fans | ||||||
| Models | 9219 | 9218 | 9214 | 9212 | ||
|---|---|---|---|---|---|---|
| Blade Size | 18″ | 18″ | 14″ | 12″ | ||
| CFM (High/Med/Low) | 3190 / 2970 / 2660 | 3190 / 2970 / 2660 | 1650 / 1470 / 1180 | 1360 / 1170 / 1010 | ||
| RPM (High/Med/Low) | 1500 / 1300 / 1100 | 1500 / 1300 / 1100 | 1498 / 1296 / 934 | 1545 / 1205 / 900 | ||
| AMPS (High/Med/Low) | 1.5 / 1.3 / 1.0 | 1.5 / 1.3 / 1.0 | 0.6 / 0.5 / 0.4 | 0.8 / 0.6 / 0.5 | ||
| Watts (High/Med/Low) | 180 / 150 / 125 | 180 / 150 / 125 | 63 / 56 / 48 | 85 / 76 / 64 | ||
| dB (High/Med/Low) | 67 / 58 / 49 | 67 / 58 / 49 | 58 / 55 / 48 | 56 / 49 / 42 | ||
| Adjustable Height | 26″ / 28″ | N/A | N/A | N/A | ||
| Pivoting Head | Yes | Yes | Yes | Yes | ||
| Weight (lbs.) | 27.9 | 21.4 | 13.6 | 12.1 | ||
| Cube (feet) | 4.44 | 3.17 | 1.98 | 1.43 | ||
| Dimensions (Length/Width/Height) | 24″ x 25″ x 48″ | 22″ x 9.75″ x 22″ | 18.75″ x 9″ x 18″ | 15.5″ x 8.5″ x 16.5″ | ||
| Specification Sheet | 9219 | 9218 | 9214 | 9212 | ||
Download Instructions
9230
9224
9220
9219
9218
9214
9212
Download Specification Sheets
9230
9224
9220
9219
9218
9214
9212
9230, 9224: Assembled fan head, floor stand and wheels with assembly hardware
9220, 9218, 9214, 9212: Assembled fan head with attached floor stand
9219: Assembled fan head, roll about stand with assembly hardware
